Carpa de almacén temporal de 20 m x 40 m con luz libre​

40m Clear Span Industrial Tent
big storage tent
Industrial Tent for sale
outdoor storage tent
Temporary Warehouse Tent sale
huge outdoor warehouse tent
storehouse tent
warehouse tent with aluminum

20m-40m Temporary Warehouse Tent

Acerca del proyecto

The new thermal PVC waterproof storage tent is the latest warehouse tent series from Liri Tent. Besides the performance of the original warehouse tent, the thermal insulation roof can be good for heat isolation and snow loading. This product is the latest warehouse tent in China. The benefits of using the temporary warehouse tent​ are:

  1. Short construction time: It takes 3 to 4 days to assemble a 1,000sqm temporary warehouse tent.
  2. Materials are 100% reusable when moving to another area.
  3. The wall system has options for a sandwich panel hard wall and PVC wall to satisfy different needs. The structure is able to extend to unlimited lengths.
  4. Rolling door system can be used for loading entrance for truck or forklift from four sides of the warehouse tent.
  5. Roof cover uses 650-850g/m2 coated PVC polyester textile and flame retardant to DIN 4102 BI, M2.
  6. The volume of the whole structure uses little space for storage and transportation.
  7. The thermal insulation roof tent is able to resist snow loading of three levels. These levels include 25kg,50kg, or 75kg, which can protect you from most of the weather conditions.
Especificaciones de la serie de carpas industriales
Ancho de vanoAltura del aleroAltura de la crestaDistancia entre módulosPerfil principal
5 m4,2 m5,05 m5 m204 x 120 x 4 mm (4 canales)
7,5 m4,2 m5,46 m5 m204 x 120 x 4 mm (4 canales)
10 m4,2 m5,84 m5 m204 x 120 x 4 mm (4 canales)
12 m4,2 m6,16 m5 m204 x 120 x 4 mm (4 canales)
15 m5,2 m7,6 m5 m256 x 121 x 5 mm (4 canales)
20 m5,2 m8,4 m5 m256 x 121 x 5 mm (4 canales)
25 m5,2 m9,2 m5 m300 x 120 x 5 mm (4 canales)
30 m5,2 m10 m5 m350 x 120 x 5 mm (4 canales)
Características

Perfiles de la estructura: aluminio extruido 6061/T6 (15HW) de alta resistencia

Revestimiento de tejido: tejido de poliéster de alta calidad con doble recubrimiento de PVC; impermeable 100%; ignífugo según las normas DIN 4102 B1, M2 y CFM; resistente a los rayos UV, resistente al desgarro, con capacidad de autolimpieza, etc.

Conectores: acero resistente galvanizado en caliente

Rango de temperatura admisible: de -30 °C a +70 °C

Resistencia al viento: máx. 100 km/h

Carga de nieve: 75 kg/m² (la nieve no se acumula con un techo de gran pendiente)

Fácil de montar y desmontar

Sin postes interiores, 100 % del espacio interior disponible
